ROOKIE RD
10W, 15W, 25W, 35W, 45W
ROOKIE RD is a recessed indoor downlight designed to deliver efficient and uniform illumination. With its compact design and reliable performance, it is ideal for residential and commercial interior applications, offering a clean and modern ceiling appearance.
| CCT | 3000K, 4000K, 6500K |
|---|---|
| Wattage |
Suitable for :
- Retail Spaces
- Office & Commercial Spaces
- Healthcare Spaces
- Lobbies
- Features
- Specifications
- Technical Data
- Downloads
- Flexible Mounting – Surface or pendant installation options
- Enhanced visual comfort
- Long Life: 50,000+ hrs – Minimal maintenance
- Uniform light distribution
- Easy installation
| Housing | Aluminium Die Cast with Clear Glass | |
| Body Colour | Black/White | |
| Light Source | COB | |
| Control Options | On/Off, Phase Dimming, 1-10V, DALI | |
| Rated Luminous Efficacy | 100 lm/W | |
| Lifetime | >50,000 hours | |
| Input Voltage | 220-240 VAC | |
| Input Frequency | 50-60 Hz | |
| Efficiency | >90% | |
| IP Rating | IP44 | |
| IK Rating | IK02 |
| Model No. | Power (W) | Lumens (lm) | CCT (K) | CRI | Beam Angle (Deg°) | Dimensions (mm) | |||
| CL-RD-10 | 10 | 1,000 | 3000 / 4000 / 6500 | ≥80 | 50 | D:90, H:90 | |||
| CL-RD-15 | 15 | 1,500 | 3000 / 4000 / 6500 | ≥80 | 50 | D:112, H:122 | |||
| CL-RD-25 | 25 | 2,500 | 33000 / 4000 / 6500 | ≥80 | 44 | D:129, H:155 | |||
| CL-RD-35 | 35 | 3,500 | 3000 / 4000 / 6500 | ≥80 | 51 | D:170, H:184 | |||
| CL-RD-45 | 45 | 4,500 | 3000 / 4000 / 6500 | ≥80 | 53 | D:194, H:194 |
*D=Diameter; H=Height
