ROOKIE SQ
10W, 15W, 25W, 35W
ROOKIE SQ is a square recessed indoor downlight designed to deliver efficient and uniform illumination. Its clean geometric design and reliable performance make it ideal for modern residential and commercial interior applications.
| CCT | 3000K, 4000K, 6500K |
|---|---|
| Wattage | 10W, 15W, 25W, 35W |
Suitable for :
- Retail Spaces
- Office & Commercial Spaces
- Healthcare Spaces
- Lobbies
-
Features
-
Specifications
-
Technical Data
-
Downloads
- Flexible Mounting โ Surface or pendant installation options
- Enhanced visual comfort
- Long Life: 50,000+ hrs โ Minimal maintenance
- Uniform light distribution
- Easy installation
| Housing | Aluminium Die Cast with Clear Glass | |
| Body Colour | Black/White | |
| Light Source | COB | |
| Control Options | On/Off, Phase Dimming, 1-10V, DALI | |
| Rated Luminous Efficacy | 100 lm/W | |
| Lifetime | >50,000 hours | |
| Input Voltage | 220-240 VAC | |
| Input Frequency | 50-60 Hz | |
| Efficiency | >90% | |
| IP Rating | IP44 | |
| IK Rating | IK02 |
| Model No. | Power (W) | Lumens (lm) | CCT (K) | CRI | Beam Angle (Degยฐ) | Dimensions (mm) | |||
| CL-SQ-10 | 10 | 1,000 | 3000 / 4000 / 6500 | โฅ80 | 51 | L: 90, W:90, H:91 | |||
| CL-SQ-15 | 15 | 1,500 | 3000 / 4000 / 6500 | โฅ80 | 48 | L:110, W:110, H:122 | |||
| CL-SQ-25 | 25 | 2,500 | 33000 / 4000 / 6500 | โฅ80 | 43 | L:130, W:130, H:133 | |||
| CL-SQ-35 | 35 | 3,500 | 3000 / 4000 / 6500 | โฅ80 | 52 | L:160, W:160, H:164 |
*L= Length ,W= Width, H= Height
