PETRA ECO
10W, 18W, 30W
The Petra ECO Recessed Downlight is a high-performance lighting solution designed for durability and in modern applications. Featuring IP65 protection, it is resistant to dust and water, making it suitable for both indoor and semi-outdoor environments.
| CCT | 3000K, 4000K, 6500K |
|---|---|
| Wattage | 10W, 18W, 30W |
Suitable for :
- Retail Spaces
- Office & Commercial Spaces
- Healthcare Spaces
- Lobbies
-
Features
-
Specifications
-
Technical Data
-
Downloads
- IP65 protection from dust and water
- Efficient COB illumination
- Durable die-cast housing
- Multiple beam-angle options
- Quick recessed installation
| Housing | Aluminium Die Cast with PC Lens | |
| Body Colour | White/Black | |
| Light Source | COB | |
| Control Option | On/Off, Phase Dimming, 1-10V, DALI | |
| Rated Luminous Efficacy | 100 lm/W | |
| Lifetime | >50,000 hours | |
| Input Voltage | 220-240 VAC | |
| Input Frequency | 50-60 Hz | |
| Power Factor | โฅ0.9 | |
| IP Rating | IP65 | |
| IK Rating | IK02 |
| Model No. | Power (W) | Lumens (lm) | CCT (K) | CRI | Beam Angle (Degยฐ) | Dimensions (mm) | |||
| PCB-ECO-10 | 10 | 1,000 | 3000 / 4000 / 6500 | โฅ80 | 46 | D:90, H:50, CUTOUT:75 | |||
| PCB-ECO-18 | 18 | 1,800 | 3000 / 4000 / 6500 | โฅ80 | 55 | D:110, H:58, CUTOUT:95 | |||
| PCB-ECO-30 | 30 | 3,000 | 3000 / 4000 / 6500 | โฅ80 | 49 | D:135, H:65, CUTOUT:115 |
*D=Diameter; H=Height
