ARC 7 DC
UP TO 80W
Arc 7 DC is a high-performance DC pole top light designed for efficient and uniform outdoor illumination. It is ideal for solar powered, battery-based, and off-grid lighting applications. Suitable for parks and gardens, pedestrian pathways, parking areas, residential communities, and recreational spaces, where consistent and efficient lighting is essential.
| CCT | 2700K – 3000K |
|---|---|
| Wattage | UP TO 80W |
Suitable for :
- Commercial complexes
- Parks
- Urban & Residential
- Streets
- Features
- Specifications
- Technical Data
- Downloads
- ROBUST ALUMINIUM BODY : Constructed from high-grade aluminium
- WEATHER-RESISTANT CONSTRUCTION : Corrosion-resistant construction for long-lasting outdoor performance
- POWDER-COATED FINISH : Finished with a premium outdoor powder coating
- PRECISION DIE-CASTING ENSURES UNIFORM QUALITY AND SMOOTH FINISH : Minimizes surface defects and improves durability
| PRODUCT NAME | ARC 7 DC | |
| PRODUCT TYPE | LED POLE TOP LIGHT | |
| PRODUCT CODE | ARC7DC-PTS-80W-XXXXK | |
| AVAILABLE CCT | 2700K - 3000K | |
| BODY MATERIAL | CORROSION-RESISTANT ALUMINIUM DIE-CAST | |
| LENS | UV-STABILIZED POLYCARBONATE (PC) LENS | |
| BODY COLOR | GREY / SPECIAL | |
| CONTROLLER TYPE | MPPT (Maximum Power Point Tracking) Solar Charge Controller | |
| RATED LUMINOUS EFFICACY | 110.24 lm/W | |
| IP RATING | IP66 | |
| IK RATING | IK08 | |
| AMBIENT TEMPERATURE (TA) | -20°C to +50°C | |
| HUMIDITY | RH 10–95% |
| Model No. | Power (W) | Lumens (lm) | CCT (K) | CRI | ULOR(Upward Light Output Ratio) | Beam Angle (Deg°) | Dimensions (mm) | ||
| ARC7DC-PTS-80W-XXXXK | UP TO 80 | 8616 | 2700/3000 | ≥80 | 0% (U0 – Zero Uplight) | 97.9 | H: 700, D: 462, PD: 60 |
*H=Height; D=Dia; PD=Pole Dia;
