ECLIPSE
10W, 12W, 20W, 25W, 35W
ECLIPSE is a sleek and modern recessed spotlight designed to deliver focused and high-quality illumination. With its compact form and elegant finish, it blends seamlessly into ceilings, making it ideal for contemporary architectural and interior lighting applications.
| CCT | 3000K, 4000K, 6500K |
|---|---|
| Wattage | 10W, 12W, 20W, 25W, 35W |
Suitable for :
- Residential Spaces
- Office & Commercial Spaces
- Showrooms & Display Areas
- Galleries
-
Features
-
Specifications
-
Technical Data
-
Downloads
- Precision recessed design
- Low-glare visual comfort
- Durable die-cast body
- Consistent Performance & Quality - Delivers stable brightness.
| Housing | Aluminium Die Cast with PC Lens | |
| Body Colour | Grey | |
| Light Source | COB | |
| Control Options | On/Off, Phase Dimming, 1-10V, DALI | |
| Rated luminous efficacy | 100 lm/W | |
| Lifetime | >50,000 hours | |
| Input voltage | 220-240 VAC | |
| Input frequency | 50-60 Hz | |
| Efficiency | >90% | |
| IP Rating | IP44 | |
| IK Rating | IK02 |
| Model | Power | Lumens (lm) | CCT (K) | CRI | Beam Angle (Degยฐ) | Dimensions (mm) | |||
| ECL-DL-10 | 10 | 1,000 | 3000 / 4000 / 6500 | โฅ80 | 24 | D:64, H:87, CUTOUT:55 | |||
| ECL-DL-12 | 12 | 1,200 | 3000 / 4000 / 6500 | โฅ80 | 35 | D:85, H:92, CUTOUT:75 | |||
| ECL-DL-20 | 20 | 2,000 | 3000 / 4000 / 6500 | โฅ80 | 37 | D:85, H:100, CUTOUT:75 | |||
| ECL-DL-25 | 25 | 2,500 | 3000 / 4000 / 6500 | โฅ80 | 34 | D:105, H:120, CUTOUT:95 | |||
| ECL-DL-35 | 35 | 3,500 | 3000 / 4000 / 6500 | โฅ80 | 34 | D:105, H:150, CUTOUT:95 |
*D=Diameter; H=Height
