CROSSBOW UFO
100W, 150W, 200W, 300W
CROSSBOW UFO is a highbay LED luminaire designed for suspended mounting (chains, wires, etc.) in indoor and outdoor applications. It delivers high luminous efficacy for greater light output,Its compact UFO design suits Industrial & Infrastructure, Transportation Areas, Storage Areas and Warehouses
| CCT | 3000K, 4000K, 6500K |
|---|---|
| Wattage | 100W, 150W, 200W, 300W |
Suitable for :
- Industrial & Infrastructure
- Warehouses
- Transportation Areas
- Storage Areas
- Features
- Specifications
- Technical Data
- Downloads
- High Luminous efficacy - More light output
- Efficient Heat Dissipation – Die-cast aluminum housing
- Long life: 50,000+ hrs - Minimal maintenance
- Compact UFO design – Ideal for industrial and commercial spaces
- Consistent Performance & Quality - Delivers stable brightness
| Housing | Aluminium Die Cast Body with PC Lens | |
| Body Colour | Black | |
| Light Source | SMD | |
| Control Options | ON/OFF, 1-10V, DALI | |
| Rated Luminous Efficacy | 140 lm/W | |
| Lifetime | >50,000 hours | |
| Input Voltage | 220-240 VAC | |
| Input Frequency | 50-60 Hz | |
| Efficiency | >90% | |
| IP Rating | IP65 | |
| IK Rating | IK08 |
| Model No. | Power (W) | Lumens | CCT | CRI | Beam Angle | Dimensions (mm) | |||
| HBL-UFO-100 | 100 | 14000 | 3000K/4000K/6500K | ≥80 | 85.5° | D:250,W:NA,H:160 mm | |||
| HBL-UFO-150 | 150 | 21000 | 3000K/4000K/6500K | ≥80 | 83.9° | D:305,W:NA,H:160 mm | |||
| HBL-UFO-200 | 200 | 28000 | 3000K/4000K/6500K | >80 | 85.3° | D:350,W:NA,H:160 mm | |||
| HBL-UFO-400 | 400 | 42000 | 3000K/4000K/6500K | ≥80 | 88.9° | D:490,W:NA,H:160 mm |
*D=Diameter; H=Height
