LUMIBROOK CON 5FT
60W, 70W, 80W
LUMIBROOK CON is a robust and efficient weatherproof LED linear light designed for demanding environments. With its sealed construction and durable body, it offers reliable performance in areas exposed to dust, moisture, and water
| CCT | 3000K, 4000K, 6500K |
|---|---|
| Wattage | 60W, 70W, 80W |
Suitable for :
- Parking Areas
- Industrial & Infrastructure
- Transportation Areas
- Service Areas
-
Features
-
Specifications
-
Technical Data
-
Downloads
- Quick & easy installation
- Consistent output
- PC diffuser for long life
- Tool-free clips for effortless servicing
- Dust & moisture proof
| Housing | ABS Plastics with PC Diffuser | |
| Body Colour | Green Grey / Light Grey | |
| Light Source | SMD | |
| Control Option | On/Off, Phase Dimming, 1-10V, DALI | |
| Rated Luminous Efficacy | 120 lm/W | |
| Lifetime | >50,000 hours | |
| Input Voltage | 220-240 VAC | |
| Input Frequency | 50-60 Hz | |
| Power Factor | โฅ0.9 | |
| IP Rating | IP65 | |
| IK Rating | IK09 |
| Model No. | Power (W) | Lumens (lm) | CCT (K) | CRI | Beam Angle (Degยฐ) | Dimensions (mm) | |||
| LBK-CON-5F-60 | 60 | 7,200 | 3000 / 4000 / 6500 | โฅ80 | 123 | L:1500, W:74, H69 | |||
| LBK-CON-5F-70 | 70 | 8,400 | 3000 / 4000 / 6500 | โฅ80 | 123 | L:1500, W:74, H69 | |||
| LBK-CON-5F-80 | 80 | 9,600 | 3000 / 4000 / 6500 | โฅ80 | 123 | L:1500, W:74, H69 |
*L= Length ,W= Width, H= Height
