CIVIC 2T
200W, 400W, 600W, 800W, 1000W, 1200W
| Civic 2T is a high-performance IP66-rated façade and sports light designed for reliable outdoor illumination. Its robust construction provides complete protection against dust and water, ensuring consistent performance even in harsh weather conditions. |
| CCT | 3000K, 4000K, 5700K |
|---|---|
| Wattage | 200W, 400W, 600W, 800W, 1000W, 1200W |
Suitable for :
- Sports & Recreational Area
- Industrial & Infrastructure
- Outdooor & Area lightting
- Transportation & Utility
-
Features
-
Specifications
-
Technical Data
-
Downloads
- High Luminous efficacy -More light output
- Efficient Heat Dissipation – Die-cast aluminum housing
- Long life: 50,000+ hrs - Minimal maintenance
- Adjustable Bracket – Easy installation & aiming
- Consistent Performance & Quality - Delivers stable brightness
| Housing | Aluminium Die Cast with PC Lens | |
| Body Colour | Grey | |
| Light Source | SMD | |
| Control Option | On/Off, 1-10V, DALI | |
| Rated Luminous Efficacy | 140 lm/W | |
| Lifetime | >50,000 hours | |
| Input Voltage | 220-240 VAC | |
| Input Frequency | 50-60 Hz | |
| Power Factor | ≥0.9 | |
| IP Rating | IP66 | |
| IK Rating | IK10 |
| Model No. | Power (W) | Lumens (lm) | CCT (K) | CRI | Beam Angle (Deg°) | Dimensions (mm) | |||
| CV2T-FLD-200 | 200 | 28,000 | 3000 / 4000 / 6500 | ≥80 | 74.2 | L:440, W:145, H:160 | |||
| CV2T-FLD-400 | 400 | 56,000 | 3000 / 4000 / 6500 | ≥80 | 73.1 | L:445, W:315, H:160 | |||
| CV2T-FLD-600 | 600 | 84,000 | 3000 / 4000 / 6500 | ≥80 | 71.2 | L:445, W:480, H:160 | |||
| CV2T-FLD-800 | 800 | 112,000 | 3000 / 4000 / 6500 | ≥80 | 71.2 | L:445, W:640, H:160 | |||
| CV2T-FLD-1000 | 1000 | 140,000 | 3000 / 4000 / 6500 | ≥80 | 71.2 | L:445, W:810, H:160 | |||
| CV2T-FLD-1200 | 1200 | 168,000 | 3000 / 4000 / 6500 | ≥80 | 71.2 | L::865, W:485, H:160 |
*L=Length; W=Width; H=Height
