STELLAR
3W, 7W, 12W, 18W
STELLAR is a sleek indoor recessed light designed to deliver efficient and uniform illumination. With its modern design and high-quality construction, it is ideal for residential and commercial interiors, providing both aesthetic appeal and reliable performance.
| CCT | 3000K, 4000K, 6500K |
|---|---|
| Wattage | 3W, 7W, 12W, 18W |
Suitable for :
- Retail Spaces
- Office & Commercial Spaces
- Healthcare Spaces
- Lobbies
-
Features
-
Specifications
-
Technical Data
-
Downloads
- Durable aluminium die-cast body
- Strong thermal heat management
- Multiple reflector colour options
- IP44-rated for moisture and dust resistance
- Stable long-term illumination
| Housing | Aluminium Die Cast with Frosted PC Lens | |
| Body Colour | White | |
| Light Source | SMD/COB | |
| Control Option | On/Off, Phase Dimming, 1-10V, DALI | |
| Rated Luminous Efficacy | 100 lm/W | |
| Lifetime | >50,000 hours | |
| Input Voltage | 220-240 VAC | |
| Input Frequency | 50-60 Hz | |
| Power Factor | โฅ0.9 | |
| IP Rating | IP44 | |
| IK Rating | IK02 |
| Model No. | Power (W) | Lumens (lm) | CCT (K) | CRI | Beam Angle (Degยฐ) | Dimensions (mm) | |||
| STR-DL-03 | 3 | 300 | 3000 / 4000 / 6500 | โฅ80 | 52 | D:41, H:47, CUTOUT:35 | |||
| STR-DL-07 | 7 | 700 | 3000 / 4000 / 6500 | โฅ80 | 44 | D:63, H:48, CUTOUT:55 | |||
| STR-DL-12 | 12 | 1,200 | 3000 / 4000 / 6500 | โฅ80 | 46 | D:84, H:47, CUTOUT:75 | |||
| STR-DL-18 | 18 | 1,800 | 3000 / 4000 / 6500 | โฅ80 | 53 | D:105, H:70, CUTOUT:90 |
*D=Diameter; H=Height
