QUASIMOND
15W
QUASIMOND is a durable and high-performance LED bulkhead light designed for reliable illumination in both indoor and outdoor environments. With its rugged construction and weather-resistant design, it ensures consistent performance in areas exposed to dust, moisture, and impact.
| CCT | 3000K, 4000K, 6500K |
|---|---|
| Wattage | 7W, 10W, 12W, 15W, 20W, 30W |
Suitable for :
- Balconies
- Staircases
- Service & Basements Areas
- Outdoor Corridors
-
Features
-
Specifications
-
Technical Data
-
Downloads
- Durable & long-lasting
- Dust & moisture proof
- Smooth and even illumination
- Reliable long-term performance
- Quick and easy installation
| Housing | Aluminium Die Cast with PC Diffuser | |
| Body Colour | Grey/Black | |
| Light Source | SMD | |
| Control Option | On/Off, Phase Dimming, 1-10V, DALI | |
| Rated Luminous Efficacy | 100 lm/W | |
| Lifetime | >50,000 hours | |
| Input Voltage | 220-240 VAC | |
| Input Frequency | 50-60 Hz | |
| Power Factor | โฅ0.9 | |
| IP Rating | IP65 | |
| IK Rating | IK02 |
| Model No. | Power (W) | Lumens (lm) | CCT (K) | CRI | Beam Angle (Degยฐ) | Dimensions (mm) | |||
| QM-WL-15 | 15 | 1,500 | 3000 / 4000 / 6500 | โฅ80 | 112 | L:215, W: 132, H:60 |
*L= Length, W= Width, H= Height
