FALCON G
40W, 60W, 80W, 100W, 120W, 150W, 180W, 200W, 240W
It is a high-performance outdoor lighting solution engineered for modern urban and roadway applications. Designed with advanced LED technology and robust construction, it delivers superior brightness, energy efficiency, and long-term reliability. Its sleek aerodynamic design enhances both functionality and aesthetic appeal, making it ideal for city streets, highways, and public areas.
| CCT | 3000K, 4000K, 5700K, 6500K |
|---|---|
| Wattage | 40W, 60W, 80W, 100W, 120W, 150W, 180W, 200W, 240W |
Suitable for :
- Highways
- Urban&Residential
- Open Car parks
- Fuel Stations
-
Features
-
Specifications
-
Technical Data
-
Downloads
- Tool Free - Easy maintenance.
- Multiple Beam Choices – adaptable for any space.
- High Luminous Efficacy -More light output.
- Efficient Heat Dissipation – Die-cast aluminum housing.
- Consistent Performance & Quality - Delivers stable brightness
| Housing | Aluminium Die Cast Body With PC Lens & Tempered Glass | |
| Body Colour | Grey | |
| Light Source | Bridgelux | |
| Control Gear | Inventronics | |
| Control Options | ON/OFF, 1-10V, DALI | |
| Rated Luminous Efficacy | 160 lm/W | |
| Lifetime | >50,000 hours | |
| Input Voltage | 220-240 VAC | |
| Input Frequency | 50-60 Hz | |
| Efficiency | >90% | |
| IP Rating | IP66 | |
| IK Rating | IK10 |
| Model No. | Power (W) | Lumens | CCT | CRI | Beam Angle | Dimensions (mm) | |||
| Falcon G-40 | 40 | 6400 | 3000K/4000K/5700K/6500K | ≥70 | Type I, II, III, IV, V | L/D:550,W:200,H:113, ARM DIA:68 mm | |||
| Falcon G-60 | 60 | 9600 | 3000K/4000K/5700K/6500K | ≥70 | Type I, II, III, IV, V | L/D:550,W:200,H:113, ARM DIA:68 mm | |||
| Falcon G-80 | 80 | 12800 | 3000K/4000K/5700K/6500K | ≥70 | Type I, II, III, IV, V | L/D:602,W:243,H:101, ARM DIA:68 mm | |||
| Falcon G-100 | 100 | 16000 | 3000K/4000K/5700K/6500K | ≥70 | Type I, II, III, IV, V | L/D:602,W:243,H:101, ARM DIA:68 mm | |||
| Falcon G-120 | 120 | 19200 | 3000K/4000K/5700K/6500K | ≥70 | Type I, II, III, IV, V | L/D:652,W:263,H:121, ARM DIA:68 mm | |||
| Falcon G-150 | 150 | 24000 | 3000K/4000K/5700K/6500K | ≥70 | Type I, II, III, IV, V | L/D:652,W:263,H:121, ARM DIA:68 mm | |||
| Falcon G-180 | 180 | 28800 | 3000K/4000K/5700K/6500K | ≥70 | Type I, II, III, IV, V | L/D:823,W:314,H:121, ARM DIA:68 mm | |||
| Falcon G-200 | 200 | 32000 | 3000K/4000K/5700K/6500K | ≥70 | Type I, II, III, IV, V | L/D:823,W:314,H:121, ARM DIA:68 mm | |||
| Falcon G-240 | 240 | 38400 | 3000K/4000K/5700K/6500K | ≥70 | Type I, II, III, IV, V | L/D:823,W:314,H:121, ARM DIA:68 mm |
*D=Diameter; H=Height
