Civic F
50W, 100W, 150W, 200W, 250W, 300W, 400W, 500W
This range of products is popular for a wide range of applications, such as Outdoor/Indoor stadiums, Galleries, and Industrial areas CIVIC F is a versatile LED FLOOD Light that can be used widely Outdoors, easy to mount on the wall surfaces and Post tops. The luminaire offers a broad range of power, color temperatures and options like timer and sleep function.
| CCT | 3000K, 4000K, 6500K |
|---|---|
| Wattage | 50W, 100W, 150W, 200W, 250W, 300W, 400W, 500W |
Suitable for :
- Sports & Recreational Area
- Industrial & Infrastructure
- Outdooor & Area lightting
- Transportation & Utility
-
Features
-
Specifications
-
Technical Data
-
Downloads
- High Luminous efficacy - More light output
- Efficient Heat Dissipation โ Aluminum Die Cast housing
- Long life: 50,000+ hrs - Minimal maintenance
- Adjustable Bracket โ Easy installation & aiming
- Consistent Performance & Quality - Delivers stable brightness
| Housing | Aluminium Die Cast Body With PC Lens | |
| Body Colour | Black | |
| Light Source | Bridgelux | |
| Control Gear | Inventronics | |
| Control Options | ON/OFF, 1-10V, DALI | |
| Rated Luminous Efficacy | 140 lm/W | |
| Lifetime | >50,000 hours | |
| Input Voltage | 100-240 VAC | |
| Input Frequency | 50-60 Hz | |
| Efficiency | >90% | |
| IP Rating | IP66 | |
| IK Rating | IK10 |
| Model No. | Power (W) | Lumens | CCT | CRI | Beam Angle | Dimensions (mm) | |||
| CVF-FLD-050 | 50 | 7000 | 3000K/4000K/6500K | โฅ80 | 90.2ยฐ | L/D:87,W:315,H:230 mm | |||
| CVF-FLD-0100 | 100 | 14000 | 3000K/4000K/6500K | โฅ80 | 93.3ยฐ | L/D:185,W:315,H:230 mm | |||
| CVF-FLD-0150 | 150 | 21000 | 3000K/4000K/6500K | โฅ80 | 83.3ยฐ | L/D:280,W:315,H:230 mm | |||
| CVF-FLD-0200 | 200 | 28000 | 3000K/4000K/6500K | โฅ80 | 91.5ยฐ | L/D:375,W:315,H:220 mm | |||
| CVF-FLD-0250 | 250 | 35000 | 3000K/4000K/6500K | โฅ80 | 91.5ยฐ | L/D:475,W:315,H:220 mm | |||
| CVF-FLD-0300 | 300 | 42000 | 3000K/4000K/6500K | โฅ80 | 94.0ยฐ | L/D:570,W:315,H:220 mm | |||
| CVF-FLD-0400 | 400 | 56000 | 3000K/4000K/6500K | โฅ80 | 91.5ยฐ | L/D:375,W:645,H:220 mm | |||
| CVF-FLD-0500 | 500 | 70000 | 3000K/4000K/6500K | โฅ80 | 91.5ยฐ | L/D:475,W:645,H:220 mm |
*D=Diameter; H=Height
