Compass H
15W, 20W
Compass H is an LED Bulk Head Light that is designed to be mounted on a wall or ceiling, often in outdoor or industrial
settings.This product line is popular for lighting up balconies, staircases, and corridors
| CCT | 3000K, 4000K, 6500K |
|---|---|
| Wattage | 15W, 20W |
Suitable for :
- Balconies
- Staircases
- Transportation Areas
- Outdoor Corridors
-
Description
-
Features
-
Specifications
-
Technical Data
-
Downloads
- Semi-Circular Design – Provides uniform and stylish lighting.
- LongLife: 50,000 hrs- Minimal maintenance.
- Consistent Performance & Quality - Delivers stable brightness.
- Diffused Illumination – Soft, uniform, glare-free light.
- IP65 Rated – Protection against dust and water
| Housing | Aluminium Die Cast Body with PC Diffuser | |
| Body Colour | Black/Grey | |
| Light Source | Bridgelux | |
| Control Gear | Tridonic | |
| Control Option | ON/OFF, PHASE DIMMING, 1-10V, DALI | |
| Rated Luminous Efficacy | 100 lm/W | |
| LED Life Time | >50,000 hours | |
| Input Voltage | 220-240 VAC | |
| Input Frequency | 50-60 Hz | |
| Efficiency | >90% | |
| IP Rating | IP65 | |
| IK Rating | IK09 |
| Model No. | Power (W) | Lumens | CCT | CRI | Beam Angle | Dimensions | |||
| BLK-CH-15 | 15 | 1500 | 3000K/4000K/6500K | >80 | 114.1° | L/D:223,W:NA,H:75 mm | |||
| BLK-CH-20 | 20 | 2000 | 3000K/4000K/6500K | >80 | 114.1° | L/D:275,W:NA,H:85mm |
*D=Diameter; H=Height
